Overview:
Up to 250 kHz switching frequency
Standard +15/-5 volts drive (can be provided with other preferable options)
Direct 3.3v and 5v pulse support, no need of additional interfacing circuit
8A peak current drive capability
On board isolated supplies
Half-bridge drive with inbuilt dead band option available
Buffered inputs for low noise
Under voltage lock out protection
Short-circuit protection using VCESAT and Fault feedback
Up to 1000 volts DC link support
Power and fault indication LED
Dimension: 80mm × 65mm
Applications:
This gate driver is suitable for any application for switching frequency up to 250kHz. Some of targeted applications are:
Motor & traction drives
PFC converters
DAB converters
Multi-level converters
Industrial automation & testing
